| Model Name |
Gemini T Pro |
| Case Form Factor |
Mid-Tower |
| Dimensions (WxHxD) |
227 x 535 x 527 (mm)
8.9 x 21.0 x 20.7 (in) |
| Motherboard Formats |
Mini ITX / Micro ATX / ATX / CEB |
| I/O Panel |
USB 3.1 Type-C x 1 / USB3.0 x 2, Mic x 1 / Audio x 1, RGB Control Button |
| 3.5″ Drive Bay |
2 |
| 2.5″ Drive Bay |
3 (With five possible locations within the case) |
| Expansion Slots |
7+2 |
| Cooling System |
Front |
140mm x 2 / 120mm x 3 (1 x 120mm fan pre-installed) |
| Top |
140mm x 2 / 120mm x 3 |
| Rear |
120mm x 1 (pre-installed) |
| Side |
120mm x 2 |
| Maximum Number of Fans |
9 Max. |
| Water Cooling Support |
Front |
360mm / 280mm / 240mm / 140mm / 120mm
(Please choose either of front or side to install a radiator.) |
| Top |
360mm / 240mm / 120mm
(Please choose either of top or front to install a 360mm radiator. )
(Max. component height on motherboard is 32mm.) |
| Rear |
120mm |
| Side |
240mm / 120mm
(Please choose either of front or side to install a radiator.) |
| Max. Graphics Card Length |
400 (mm) / 15.7 (in) |
| Max. CPU Cooler Height |
170 (mm) / 6.7 (in) |
| PSU |
Standard ATX PS2 |
| Max. PSU Length |
200 (mm) / 7.9 (in) |
| Onboard Lighting System |
Trelux Lighting with Addressable RGB LEDs and Dynamic Lighting Effects
in the Front and Top Panels |
| Cable Management |
Yes |
